ReliaMed ZZA320C ReliaMed Digital TENS Unit

Features dual, isolated channels with asymmetrical, biphasic output, adjustable pulse amplitude and pulse rate. Protective caps over amplitude adjustment knobs prevent unintended changes. Liquid crystal display indicates operation modes and output. Five-mode operation: continuous; burst; modulation; strength, duration and rate modulation; and strength, duration and width modulation. Pulse rate is adjustable from 1 - 160Hz; 1 Hz/step from 1 - 20 Hz; and 5 Hz/step from 20 - 160 Hz. Pulse width is 50 ?s - 260 ?s (adjustable), 10 ?s/step. Pulse intensity is adjustable 0 - 80 mA peak into 500 ohm load into each channel, constant current. Utilizes standard lead wires and "pigtail-style" electrodes. When mode is changed, output resets to zero, then ramps up to original setting intensity to protect user from a sudden surge. Digital unit has a timer that can be set for 15-, 30- and 60-minute treatment periods; or continuous. Patient compliance feature displays treatment time in hours. Patient lock system prevents user from changing fixed parameters set by physician. Includes caps over buttons; 9-volt alkaline battery; two lead wires; four electrodes (one pack); hard, plastic carrying case; and instructions

ReliaMed ZZA320C ReliaMed Digital TENS Unit

• Dimensions: 5.0 inches (H) x 8.0 inches (W) x 10.0 inches (L)
• Weight: 4.5 pounds

• Made in Andorra
